Product Description
SircleLam Eclipse 27-27" Roll Laminator
The SircleLam Eclipse 27 is an easy-to-use and operationally intuitive 27" heated roller roll laminator with mounting capabilities designed with superior technology to provide high quality, professional laminating results. Equipped with variable temperature and speed controls, the Eclipse 27 is capable of accommodating film from 1.3 mil to 5 mil in thickness. Its quick warm-up time, easy-to-read digital display, two temperature presets, and slide away lower idler bar allow for a quick and easy laminating and film loading process. These features, combined with its 3/16" mounting capability, make it a perfect laminating solution for schools, copy shops, large offices and print-on-demand centers.
KEY FEATURES:
• Single Temperature Controller
• Variable Speed Control
• 3/16" Mounting Capable
• Horizontal End Trimmer
• 2” Diameter Silicone Heated Rollers
• Auto Shutoff
• 120 Volt Machine
• 1 Year Warrant
• Ships LTL (TRUCK)
| Specifications | |
|---|---|
| Width | 27" |
| Film Gauge | 1.5 - 5 MIL |
| Speed Range | 0-10 ft/ min |
| Heating Method | Heated Roller |
| Speed Control | Variable |
| Temperature Control | Variable + 2 Preset |
| Temperature Control | Single |
| Ready Light | Yes |
| Auto Shutoff | Yes |
| Reverse Function | Yes |
| Mounting Capability | 3/16" |
| Roller Gap Adjustment | 7 positions |
| Core Size/Core Adapter | 1" |
| Heat Roller Diameter | 2" |
| Heater Type | Quartz |
| Display Type | Digital |
| Safety Shield | Yes |
| Safety Shield Safety Switch | Yes |
| Key Pad Control | Yes |
| Warm Up Time | 12 Minutes |
| Slide Away Lower Roller Ideal Bar Release Mechanism For Easy Film Loading | Yes |
| Cooling Fans | No |
| Built-in Horizontal Trimmer | Yes |
| Cold Lamination (PSA Rewind) | No |
| Power | 120 Volt/60 Htz |
| Wattage/Amps | 1400W/12.sA |
| Dimensions | 37.75" x 18.75" x 11.5" |
| Weight/Ship Weight | 95.8/114 |
| Ships Via | LTL |
| Country of Origin | South Korea |
| Safety Approval | UL/CUL/CE |
| Diameter of Feet (For Cabinets) | 31 1/2" OD |
| Warranty | 1 Year |
| Feed Table | Aluminum Feed Tray |
| Feed Table Margin Guide | Yes |
| Feed Table Safety Switch | Yes |
| Mandrel Type | Core Adapters |
| Key Lock | Optional |
| Foot Pedal | No |
